Lecture description

An in-depth look at Layer 3 of the OSI Model (Network Layer) and examples of its usage in our networks.

Learn more from the full course

CompTIA Network+ (N10-007) Full Course & Practice Exam

CompTIA Network+ (N10-007) Bootcamp - Certification preparation course on the most popular networking certification!

14:30:22 of on-demand video • Updated April 2021

  • Passing the Network+ certification exam with confidence
  • Understanding computer networks, their functions, and their components
  • Subnetting networks
  • Performing basic network configurations
  • Becoming an effective networking technician in a small-to-medium sized business environment
English -: Now that we're at the network layer, we're concerned with routing. Layer 3 is all about how we're going to forward traffic, which we refer to as routing using logical addresses. For example, your computer has an IP address. And that IP address is either going to be an IP version 4 or an IP version 6 address, or both. Now, both of these are considered layer 3 protocols. And we're going to talk more about them as we go through this course. Now, the other thing we're going to be concerned with here is logical addressing. I mentioned that IPv4 and IPv6 are two types of logical addresses, but they're not the only logical addressing schemes that are out there. They're just the most common and most popular these days. Now, we're also going to be concerned with what's known as switching. And here, when we talk about switching, we're actually talking about layer 3 switching, which is called routing. Now, I know this gets confusing because you're using the term switching to refer to the function of routing, and when we talk about switches, the devices being layer 2 devices. So, you have to keep this straight in your head. Switches, the physical device, are layer 2. Switching is another term for routing, which is how we transfer things at the network layer, layer 3. Now, as we talk about all these, another thing that comes up is how we're going to do route discovery and selection. Now, basically, that means how do I know which way I want the traffic to go? We're going to talk a little bit more about that, too, as we go through this lesson because we're going to talk about connection services and bandwidth utilization and multiplexing strategies. All of these is at the layer 3 of the network layer. So, to start diving in deeper into these concepts, let's start out with logical addresses. There are lots of different routed protocols that have been used over the years. Back in the '80s and '90s, there was AppleTalk for Apple computers. And if you used a Windows or a Novell Network computer, you might have used IPX, which was the Internetwork Packet Exchange. Now, neither of these two are important for the Network+ certification, but it is something that I want to bring up because you may hear these terms. Really, what happened was these were both killed off by Internet Protocol, which is known as IP. This became the common protocol that everyone uses on all networks and therefore, we didn't need AppleTalk and we didn't need IPX anymore. But the point is, at layer 3, it's not just IP. There are other protocols that you could use in layer 3. IP is just the most common. Now, some of those are still existing on some legacy systems, which means old systems in some corporate network. But the routing protocol of the Internet that we use and the Internet you have at home and the network you have at home is going to be known as IP. IP comes in two variants, as I said before, IPv4 and IPv6. Now, if you look on the screen here, there's an example of an IP address. It's written as 172 .16 .254 .1. Now, we're going to look at more IP addresses in a separate lesson as we dig deeper into routing later on. For the time being, I want you to think of an IP address anytime you see a number that looks like this. There's going to be four sets of numbers, separated by dots. This is called a dotted-octet notation, and this is what an IPv4 address is going to look like. Now, how shall we actually forward or route the data across our networks? This is really the big question at layer 3. And there are three main ways for us to do this. You can use packet switching, circuit switching, or message switching. The most commonly used one in your network is going to be routing, which is also known as packet switching. This is where data is divided into packets and then each packet is forwarded on based on its IP address. Now, when I think of routing, I like to think about this as if I'm going to write a letter and send it to my mom. Let's say I put that letter in an envelope, and on the outside of the envelope, I'm going to write the address of my mom on it. I put her city and her state and the zip code. Now, I put that in the mailbox, and the mail carrier is going to take it to a central location. Here, they're going to figure out what state it goes to and then, they're going to send it to that state's post office. Once it's in that state, it's going to go down even further, and they're going to go down to the city-level post office. And then, from that city-level post office, they're going to look at where the street address is, get it to the right street, and eventually get it to her house on that street. The same kind of concept works with IP addresses. And that's the idea here. It's going to keep going and switching that packet from place to place until it gets to its final destination. In the case of my envelope, to my mom's address. Now, that's the way that packet switching is going to work for us. Every time I send a letter out, it might take a different route to get there. And I really don't care which route it takes, as long as it gets to its final destination. It's the same thing with our packets in the network. When I talk about circuit switching, though, this is where we want to have the same path each and every time. We're going to get a dedicated communications link that's established between our two devices. And if I pick up the phone to make a phone call, I'm actually going to make a virtual connection from my phone over to the other receiver's phone on the other end. So, if I pick up the phone to call you, there's going to be a temporary connection made between my phone and your phone, and all of the data that we're talking back and forth will go across the same path to get from me to you. The whole time we have this conversation going on, that's what's going to happen. That's what we call a circuit switch connection, which is different than the packet switch connection of using an envelope where we don't care where all those envelopes go as long as they got to the right place at the end. Now, when we hang up the phone and we go to make another call, it could take a different path, and that's okay. But for the entire session of us having our phone call, we want the same path, and that's what circuit switching allows us to do. Now, the third type of switching we have is known as message switching. And with message switching, this is where all the data is divided into messages, and they're similar to packet switching in this idea. But the messages can actually be stored and forwarded, more like email. So, if you go back to my mail example, maybe it gets to my mom's state, but the post office is closed because it's Sunday. So, what happens is they drop all those envelopes on the floor. Now, it's going to be held there until they open again on Monday and somebody's going to be able to pick it up, figure out where it goes, and push it along. This is what happens when you're dealing with message switching because it has a store and forward capability. If we were using just packet switching, what would end up happening is if it got to the post office and the post office was closed, it would actually just shred that envelope and nobody would ever see it. That's a bad thing if we want to make sure the data is going to get where it's going, and that's why message switching can be very useful for us. Now, almost all of our networks nowadays and the ones you utilize are going to be using packet switching, though. And the reason is we have other methods that will check if something is not getting to the distant end, and will be resent over another path until it finally gets there. So, unless you're dealing with some kind of big backend networks, you're not really going to see something like circuit switching or message switching in your normal everyday networks. Your home network, my small office network, and most of the Internet actually works using packet switching. Now, the second thing we have to talk about is route discovery and selection, how are we going to decide which path we're going to take to send that message. Well, routers are going to maintain a routing table so, they can understand how to forward a packet based on the destination IP of where it wants to get to. There are lots of different ways that it can do this, and they can do this either as a static route or dynamically-assigned route using a routing protocol like RIP, OSPF, EIGRP, and many others. Now, we're going to talk about many of those later on in this course, so we're not going to talk specifically about how it works right now. We're just going to put that to the side. But I want you to remember that routing protocols help us decide how data is going to flow across the network and how the routers are going to communicate that information. For now, let's just use the example on the screen to give us a really basic idea of how routing works. Let's say that I'm sitting in router number five at the bottom-right corner, and I want to get to router number one. Well, how should I do it? I can go from five to four to one, and that would work, but I can also go from five to four to three to two to one, and that would also work. So, how do I know which way is going to be the best way for me to go? Well, if I end up using a dynamic protocol, all of these routers continually talk to each other all the time, and they tell each other which way they know how to get to other routers and which one is the best and fastest route. So, if you think about this like streets, when you type into your GPS that you want to go from point A to point B to get to the grocery store, it may take you three or four different ways depending on the time of day, the traffic, the congestion, and a number of other factors. Routers are doing the exact same thing. They all talk to each other and they say, hey, I've got a better way for you to get from point A to point B because there's too much traffic on this direction, so, you should go and take this other route, instead. That's the idea with route discovery and route selection. Now, the next thing we need to talk about here is connection services. And connection services are going to augment our layer 2 connection services that we talked about previously and provide us with some additional reliability. Again, we're going to have some more flow control added here, and this is going to prevent the sender from sending data faster than the receiver can get it. Again, that's the way that we have flow control there, so it can say, hey, hey, hey, slow down, you're sending me too much data, or speed up, I can take more, I'm ready for more. We also have this thing called packet reordering. Now, packet reordering is really important because it allows us to take this big chunk of data, cut it up into little pieces of packets, and then, send all those packets off in different directions to get to their final destination. Now, the problem is sometimes these packets are going to arrive at the destination in the wrong order. And so, packet reordering allows them to get all this data at the end destination at the receiver, and they can take and say, okay, I got packet one and packet five and packet two and packet four and packet three, and then, I'm going to put them in the right order, one, two, three, four, five, and then I can put that data back together in what it is, and now, I have the full piece of data together. The benefit here is that because of routing, each packet gets numbered and sequenced, and so, even if they get to the other end out of order, we can put them back into the right order and read them as a coherent message. The next thing we need to talk about here at layer 3 is known as ICMP or the Internet Control Message Protocol. ICMP is used to send messages and operational information to an IP destination. The most commonly used one is known as ping, P-I-N-G. And we're going to talk specifically about that tool in our troubleshooting lecture. As you can see in this example, we can send out a single packet as a test to example.com. And when it comes back, we can then say if that site is up or down. This is what ping does. It sends out a packet and tells us if it was received or not by the distant end and how long it took. In this case, we got a response back five different times, showing that it was up and we were able to get to that distant end. Now, this is not a tool that's used regularly by end-user applications, but it is used by us as administrators to help troubleshoot our network and figure out what is up and what is down and what isn't working. Again, the most commonly used one here is going to be ping, but there's another variation of it known as traceroute, which will trace the route that a packet takes through the network and tells you every single router along the way as it goes through, essentially doing a large series of pings through each and every router so you could figure out which routes were up and which routes were down. Now, what are some examples of layer 3 devices that we need to remember for the exam? Well, the first two you have to remember are routers and multilayer switches. A router looks like this die icon here. You can see it's on the screen. It's a circle with four arrows, and this is a depiction of what a router looks like in a logical diagram. Now, a multilayer switch works like a regular switch and a router combined. So, it has both features of a layer 2 switch and a layer 3 router in the single device, which is why it's considered a layer 3 device. Again, for the exam, remember that a switch is always a layer 2 device unless they specifically tell you that it is a multilayer switch. If it's a multilayer switch, it is going to be considered a layer 3 device. Now, some other things that we have is going to be things like IPv4 and IPv6. These are both layer 3 protocols. We also have ICMP, the Internet Control Message Protocol, that we just talked about that's used in troubleshooting. All of these are found at layer 3. The best one to remember is IP and routers because these are going to be the most common ones you're going to see on test day if they ask you for examples of a layer 3 device.
